20A Range Current Sensor Module ACS712

20A Range Current Sensor Module ACS712

The 20A Range Current Sensor Module based on the ACS712 is a reliable Hall-effect current sensing solution designed for both AC and DC current measurement. It uses a precise, low-offset linear Hall circuit integrated with a copper conduction path positioned close to the sensor die. When current flows through this copper path, it generates a magnetic field which is detected by the Hall IC and converted into a proportional analog voltage output.

This non-invasive sensing method provides electrical isolation between the measured load and the control circuitry, improving safety and reducing noise interference. The module is capable of measuring currents up to ±20A, making it suitable for medium to high-power applications. The output is an analog voltage that can be easily read through the analog input pin of microcontrollers such as Arduino, AVR, PIC, ARM, and other development platforms.

The ACS712-based module is widely used in applications where monitoring and controlling current flow is essential. Typical use cases include over-current protection systems, battery charging circuits, switching power supplies, digital watt meters, inverters, motor control systems, and programmable current sources. Because it supports both AC and DC measurement, it is versatile enough for use in renewable energy systems, industrial control, robotics, and automotive electronics.

The module provides stable and accurate readings with minimal external components, making it easy to integrate into DIY and professional projects alike. The board usually includes screw terminals or solder pads for the current path (IP+ and IP-) and header pins for VCC, GND, and analog OUT connections.

Note that the color of the module PCB may vary depending on the manufacturing batch.

We also supply other variants of ACS712 current sensor modules for different measurement ranges, including the 5A Range Current Sensor Module and the 30A Range Current Sensor Module, allowing you to choose the appropriate model based on your application requirements.
